High Precision Electronic Devices Plating Gold PCBA PCB Soldering Service
Options
• Half-cut/Castellated Holes
• Impedance control
• Buried/blind vias
• Via filled with resin
• Countersinks/Counterbores
• Z-axis milling
PCB capability:
| Materials | FR-4/HTG150-180 FR-4/CEM-1/CEM-3/Aluminum |
| Number of Layer | 1-32 layers (include Rigid-Flex PCB) |
| Board Thickness | Rigid 0.2-4.0mm, Flex 0.01-0.25mm |
| Board Thickness Tolerance | 5-10% |
| Board Cutting | V-cut,Routing |
| Copper Weight | 0.2oz-10oz |
| Copper Weight Tolerance | ±0.15 oz |
| Copper Thickness | 0.5oz-5oz |
| Min Trace Width | 0.075mm |
| Min Space Width | 0.075mm |
| Min Drill Hole Diameter | 0.1mm |
| Silk Screen Min Line Width | 0.1mm |
| Color, Logo | Welcome Customization, Let Your Logo Unique. |
| Finishing | Immersion Gold, Immersion Silver, Immersion Tin, HASL, LF HASL, OSP |
| Shipping | DHL UPS EMS TNT FedEx |
| Certification | ISO 9001:2000,ISO 14001,ISO/TS16949:2002,UL E203640 |
| Prototype Cost | Negotiable. |
| Shipping | By Air or Sea. If Choose by Air, it is Faster Like You Purchase from Local Market. |
| MOQ | 1 piece. Low MOQ to Avoid Waste of Your Products and Money. |
Printed Circuit Boards Prototype (PCBs) and High Quality Customer Service
At YDY, we will do our best to offer you with the best customer experience from quote to delivery, and after sale service. We would like to cooperate with you for a long time, so high quality, fast lead time, and quick response are our factories’ advantages.
We offers 24 hours express to 48 hours express lead time for PCB express fabrication. The normal PCB fabrication time in YDY is 2-3 days for 2 layers. If you need it urgently, you could choose the express as your requirement.
We assures that we will arrange your order on time.
Delivery Shipping Process
After production and testing, your PCB orders will be sent to our shipping department. As the quick turn PCB manufacturer, our shipping department will ship your PCB quickly without any pending. For example, the 24 hours express PCB order will be shipped out in 24 hours after it is fabricated.
The same follows for the 48 hours express.
Shenzhen Yideyi Technology Co., Ltd offers mature and high-class quick turn PCB fabrication and assembly.
FAQ:
Q1. How can we ensure our information should not let third party to see our design?
We are willing to sign NDA effect by customer side local law and promising to keep customers date in high confidential level in all projects.
Q2. What service do you have?
We provide turnkey solution including RD, PCB fabrication, SMT, final assembly,testing and other value-added service.
Q3. Please note that the following detail will speed up evaluation:
Material:
Board thickness:
Copper thickness:Surface finish:
Solder mask color:
Silkscreen color:
Q4. How about the delivery?
Normally, for sample order, our delivery is about 5 days.For small batch, our delivery is about 7 days.
For mass production batch, our delivery is about 10 days.
But that depends on the real condition when we get your order.
If your order is urgently please contact us directly ,we will priority to deal it and do ourbest to give you satisfied delivery time.
Q5. With payment terms do we accept?
For sample order or small batch, we suggest you to use Pay-pal and Western Union.For mass production batch, we suggest you to use T/T.
Q6. How can we guarantee you receive an good quality product?
For PCB, we will use Flying Probe Test, E-test etc. for it.
For PCBA, we need you to offer us a method or test fixture for the function test.Before that, our inspectors will use microscope and X-ray to check the IC footwelding or bad solder etc.
Q7. What are the main products of your PCB/PCBA service?
Automotive, medical, Industrial control, Internet of Things, Smart home, military, Aerospace.
